COST-EFFECTIVE ARGB PSU
Meets 80% Efficiency
Supports Motherboard Sync Functionality
Neon-Flex RGB 30 Built-In Lighting Effects
Addressable LEDs
Support C6/C7 Power States
Automatic Fan Speed Optimization
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
Meets 80% Efficiency
Supports Motherboard Sync Functionality
Neon-Flex RGB 30 Built-In Lighting Effects
Addressable LEDs
Support C6/C7 Power States
Automatic Fan Speed Optimization
KRATOS E1 500 offers 80% energy efficiency to greatly reduce noise and operation cost. With built-in RGB lighting effects and addressable LEDs, a preferable individual style can be effortlessly achieved.
CUSTOMIZABLE AND ADAPTIVE
KRATOS E1-500 supports addressable RGB sync via motherboard manufacturer's sync software and also has 30 built-in lighting effects easily accessible with a simple button switch.
EXTRAORDINARY EFFICIENCY
KRATOS E1-500 can perfectly draw power at 80% efficiency while releasing minimal heat. With less heat generated, less noise arises.
SMART VENTILATION
The power supply unit supports automatic fan speed optimization which adjusts its fan speed according to the temperature and load.
SPECIFICATIONS
Model
KRATOS E1-500
POWER
TypeATX12V v2.4
EfficiencyMeet 80% efficiency
Support MB Sync5V 3-pin Addressable (Digital) RGB Header Only
Dimension (L x W x H)140 x 150 x 86 mm
Support C6/C7 power stateYes
AC Input100-130V;220-240V / 3.5A-7.5A / 47-63Hz
DC Output+3.3V / +5V / +12V / -12V / +5Vsb
Max. Output Current15A / 15A / 32A / 0.3A / 2.5A
Max. Output Power100W / 384W / 3.6W / 12.5W
Total Power500W
ProtectionOVP / UVP / OPP / SCP
Main Power1 (20+4 Pin)
CPU1 (4+4 Pin)
PCI-E2 (6+2 Pin)
SATA5 (5 Pin)
Molex2 (4 Pin)
Floppy1 (4 Pin)
Lighting Effect30 Neon-Flex RGB
Silent ModeNo
DC to DCNo
