- Equipped with Gen5 12VHPWR PCIe connector, meeting Intel ATX 3.0 specification standard
- Cybenetics Gold efficiency certification
- 24/7 continuous power output with 50℃operating temperature
- Fully Modular design
- All Japanese electrolytic capacitors
- Ultra silent 135mm FDB fan with semi-fanless function
12VHPWR PCIe connector supports ATX 3.0 specifications
The 12+4 pin (12VHPWR) design is capable of withstanding power failure caused by a running graphics card’s instantaneous peak power consumption, whilst providing higher stability and efficiency power output for high-end systems
Fully modular design with universal EPS / PCIe connector interface
Flat cables have much greater flexibility to allow for tighter folding and management of cable
| Specification | Details |
|---|---|
| Product No. | SST-DA1000R-GM |
| Model (safety certification) | SST-AX1000MCGD-A |
| Color | Black (lead-free paint) |
| Max. DC Output | 1000W |
| Power Density | 517W per liter |
| Load Range | |
| Output | +3.3V |
| Max. (Amps) | 22A |
| Min. (Amps) | 0A |
| Range (%) | ±3% |
| Line Reg. (%) | ±1% |
| Ripple (mVp-p) | 30mV |
| Combined +3.3V & +5V | 120W |
| Combined +12V | 1000W |
| Input Voltage | 90 ~ 264 Vrms |
| Input Frequency Range | 47Hz ~ 63Hz |
| PFC | Active PFC (PF>0.9 at full load) |
| Efficiency | ≥87% & <89% overall efficiency |
| MTBF | 100,000 hours |
| Operating Temperature | 0°C ~ 50°C |
| Protection | Over Current, Over Power, Over Voltage, Short Circuit, Under Voltage, Over Temperature, No load operation |
| Connectors | 1 x 24 / 20-Pin motherboard, 2 x 8 / 4-Pin EPS / ATX 12V, 6 x 8 / 6-Pin PCIe, 1 x 12+4-Pin 12VHPWR, 12 x SATA, 3 x 4-Pin Peripheral, 1 x 4-Pin Floppy |
| Cooling System | Silent 135mm FDB fan |
| Noise Level | 0 dBA minimum |
| Certification | Cybenetics Gold |
| Form Factor | ATX (PS2) |
| Dimension | 150mm (W) × 86mm (H) × 150mm (D) or 5.91" (W) x 3.39" (H) x 5.91" (D) |
| Weight | 2.88 kg |
| Other | GPU Support list (not provided in the provided information) |
