COLORS
Black -
LCD
Type: 70 cm / 27.5" TN colour TFT active matrix WUXGA LCD Contrast Ratio: 800:1 (typ.) Viewing Angles: 160° horizontal, 160° vertical (at 10:1)
170° horizontal, 170° vertical (at 5:1)Brightness: 500cd/m² Display Area: 59.3cm horizontal x 37.1cm vertical, 69.9cm diagonal Optimum Resolution: 1920 x 1200@60Hz Response Time: 3ms (grey-to-grey typ.), 5ms (off-on-off typ.) Light Source: Long life, 50000 hrs. (typ.) Aspect Ratio: 16:10 native (1:1, 4:3, 16:9, full screen switchable) Panel Surface: Anti-glare (3H) Pixel Pitch: 0.309mm Colour Support: 16.7M colours (6-bit+2-bit FRC) Pixel Clock: 165MHz (digital), 205MHz (analogue) -
COMPATIBILITY
PC: VGA up to 1920 x 1200 non-interlaced Mac®: Power Mac™ up to 1920 x 1200 non-interlaced -
DIMENSIONS
Physical With Stand: 662 x 578 x 306 Physical Without Stand: 662 x 489 x 87 -
PACKAGE CONTENTS
LCD Monitor, power cable, 15-pin VGA video cable, HDMI to DVI cable adapter, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language) -
AUDIO
Speaker: 2 x 3 watt integrated stereo speakers -
CONNECTOR
Analogue: 1 x 15-pin mini D-Sub VGA (detachable cable) Digital: 1 x 19-pin HDMI (HDCP enabled; detachable cable) Power: 3-pin AC plug (CEE22) Composite Video Input: 1 x RCA (CVBS) Component Video Input: 3 x RCA (YPbPr/YCbCr) Audio: 1 x 3.5mm mini stereo jack
2 x L/R RCA sets (for YPbPr and for CVBS/S-video)S-Video: 1 x 4-pin mini DIN jack (Y/C) -
POWER
Voltage: AC 100– 240V, 50/60Hz (auto switch), internal power supply Consumption: 64 watt (typ.), <1 watt in power save mode -
CONTROLS
Basic: Power, menu [1], up, down, select [2] OSD: Auto image adjust, contrast, brightness, input select (D-sub, HDMI, component, S-video, composite), audio menu (volume, mute, bass, treble, balance), View-Match® colour adjust (sRGB, 9300K, 7500K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, video format, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness, tint, colour, OptiColor mode [standard, text, cinema, game, portrait, scenery, vivid], OptiColor skin [nature, reddish, yellowish], aspect ratio [1:1, 4:3, 16:9, full screen), PIP [position, size, source], PBP [source], setup menu (language [10 options], resolution notice, OSD position, OSD timeout, OSD background, sleep timer), OSD/power lock, memory recall -
OPERATING CONDITIONS
Temperature: 5°C–35°C Humidity: 20%–80% (non-condensation) -
WEIGHT
Net With Stand: 12.0kg Net Without Stand: 8.5kg Gross: 14.3kg -
VIDEO INPUT
Frequency: Fh: 24~82kHz, Fv: 50~85Hz Sync: H/V separate (TTL), composite, sync on green Analogue: RGB analogue (0.7 Vp-p, 75 ohm), PAL, SECAM, NTSC, SDTV/EDTV (480i/p, 576i/p), HDTV (720p, 1080i) Digital: HDMI (HDCP enabled; TMDS, 100 ohm) -
POWER MANAGEMENT
Meets TCO’06 and ENERGY STAR standards -
SECURITY
Kensington® security port -
VESA MOUNT COMPLIANT
VESA FDMI 200mm x 100mm
