| Motherboard Support |
Mini-ITX, MicroATX, ATX |
| Enclosure Type |
Compact Mid-Tower |
| Case Material |
SGCC Steel, Dark Tinted Tempered Glass |
| Dimensions |
|
| Height |
460mm / 18.11 inches |
| Width |
210mm / 8.27 inches |
| Depth |
428mm / 16.85 inches |
| Weight |
7.5 kg / 16.53 lb |
| Compatibility & Clearance |
|
| Max CPU Cooler Clearance |
165mm |
| Max GPU Clearance |
338 - 368mm |
| Front Fan & Radiator Clearance |
60mm |
| Vertical GPU Clearance |
50.8mm |
| Cable Management |
19 - 23mm |
| Front I/O Ports |
|
| USB 3.2 Gen 2 Type-A |
1 |
| USB 3.2 Gen 1 Type-C |
1 |
| Headset Audio Jack |
1 |
| Smart Device |
|
| Fan Channels |
3 (10W max per channel) |
| NZXT RGB Connector |
2 (Support up to 40 LEDs) |
| Expansion Slots |
|
| Standard |
7 |
| Vertical |
2 |
| Drive Bays |
|
| 2.5" |
2 + 1 |
| 3.5" |
2 + 1 |
| Fan Support |
|
| Front |
2 x 120mm / 2 x 140mm |
| Top |
1 x 120mm / 1 x 140mm |
| Rear |
1 x 120mm |
| Filters |
All air intakes |
| Radiator Support |
|
| Front |
280mm |
| Top |
- |
| Rear |
120mm |
| Fan Specs (Aer RGB 2 140mm) |
|
| Model |
Aer RGB 2 140mm |
| Speed |
500 - 1,500 ± 300RPM |
| Airflow |
30.39 - 91.19 CFM |
| Static Pressure |
0.17 - 1.52 mm-H₂O |
| Noise |
22 - 33 dBA |
| Fan Connector |
4-pin PWM |
| Fan Specs (Aer P 140mm - Case Version) |
|
| Model |
Aer P 140mm (Case Version) |
| Speed |
1,000 ± 200RPM |
| Airflow |
68.95 CFM |
| Noise |
28 dBA |
| Fan Connector |
3-pin |
| Fan Specs (Aer P 120mm - Case Version) |
|
| Model |
Aer P 120mm (Case Version) |
| Speed |
1,200 ± 200RPM |
| Airflow |
50.42 CFM |
| Noise |
28 dBA |
| Fan Connector |
3-pin |
