| DIMENSIONS | |
|---|---|
| Height | 516mm |
| Width | 230mm |
| Depth | 494mm |
| Weight | 12.1 kg / 26.68 lb |
| COMPATIBILITY & CLEARANCE | |
|---|---|
| Max CPU Cooler Clearance | 185mm |
| Max GPU Clearance | 413mm |
| Front Fan & Radiator Clearance | 60mm |
| Top Fan & Radiator Clearance | 30mm |
| Cable Management | 18 - 22mm |
| FRONT I/O PORTS | |
|---|---|
| USB 3.2 Gen 1 Type-A | 2 |
| USB 3.2 Gen 2 Type-C | 1 |
| Headset Audio Jack | 1 |
| EXPANSION SLOTS | |
|---|---|
| Standard | 7 |
| Vertical | - |
| DRIVE BAYS | |
|---|---|
| 2.5" | 5 + 1 |
| 3.5" | 2 + 1 |
| FAN SUPPORT | |
|---|---|
| Front | 3 x 120mm / 2 x 140mm |
| Top | 3 x 120mm / 2 x 140mm |
| Rear | 1 x 120mm / 1 x 140mm |
| Filters | All air intakes |
| RADIATOR SUPPORT | |
|---|---|
| Front | 360mm |
| Top | 360mm |
| Rear | 140mm |
| FAN SPECS | |
|---|---|
| Model | Aer P 140mm (Case Version) |
| Speed | 1,000 ± 200RPM |
| Airflow | 68.95 CFM |
| Noise | 29 dBA |
| Fan Connector | 3-pin |
| FAN SPECS | |
|---|---|
| Model | Aer P 120mm (Case Version) |
| Speed | 1,200 ± 200RPM |
| Airflow | 50.42 CFM |
| Noise | 28 dBA |
| Fan Connector | 3-pin |
| GENERAL | |
|---|---|
| Warranty | 2 Years |
| Model Number | CA-H710B-W1 |
| UPC | 815671014689 |
| EAN | 5060301694983 |
