Product Specifications
| Model No. | SST-TJ10B (black), SST-TJ10B-USB3.0 (black) SST-TJ10S (silver) SST-TJ10B-W(black, with window) SST-TJ10B-W-USB3.0(black, with window) SST-TJ10S-W(silver, with window) |
|---|---|
| Material | Aluminum front panel/door, 2.0mm aluminum body |
| Motherboard | SSI EEB, Extended ATX, ATX, Micro ATX |
| Drive bay | External: 5.25” x 4, Internal: 3.5” x 1, 3.5” x 6 |
| Cooling system | Front: 1 x 120mm fan slot |
| Rear: 1 x 120mm exhaust fan, 1200rpm, 21dBA | |
| Top: 2 x 120mm fan slots | |
| Side: 1 x 120mm mid-section fan, 1200rpm, 21dBA | |
| Radiator support | Rear: 120mm x 1 |
| Top: 120mm x 2 (require RADSUPPORT09) | |
| Limitation of CPU cooler | 169mm |
| Expansion slot | 7 |
| Limitation of expansion card | Compatible up to 12" (304mm) long, width restriction-6.81" (172mm) |
| Limitation of VGA card | Full Spec |
| Power supply | 1 x Optional standard PS2 (ATX) or 1 x Redundant PS2 |
| Limitation of PSU | Unlimited |
| Front I/O port | USB 2.0 x 2 (SST-TJ10B, SST-TJ10S, SST-TJ10B-W, SST-TJ10S-W only) USB 3.0 x 2 (SST-TJ10B-USB3.0, SST-TJ10B-W-USB3.0 only) IEEE1394 x 1 audio x 1 MIC x 1 |
| Dimension | 207 mm (W) x 521 mm (H) x 644 mm (D), 69.5 liters |
| 8.15" (W) x 20.51" (H) x 25.35" (D), 69.5 liters | |
| Net weight | 13 kg |
