CAP (Cooling Apparatus)
| Property | Value |
|---|---|
| Material | Aluminum, Plastic |
| Display Orientation | Software adjustable Default, +90, +180, and -90 Degrees |
| Display Panel Active Area | 2.36” (60mm) diameter |
| Display Color | 24-bit true color LCD |
| Display Resolution | 640 x 640 px |
| Display Brightness | 690 cd/m² |
| Display Panel Type | TFT-LCD (Wide Viewing Angle) |
WATER BLOCK
| Property | Value |
|---|---|
| Dimensions | Diameter: 81.9mm, H: 59.5mm |
| Material (Block) | Copper |
| Material (Housing) | Plastic |
PUMP
| Property | Value |
|---|---|
| Motor Speed | 800 - 2,800 ± 300 RPM |
| Power | 12V DC, 0.3A |
RADIATOR
| Property | Value |
|---|---|
| Dimensions | 123 x 275 x 30mm |
| Material | Aluminum |
TUBE
| Property | Value |
|---|---|
| Length | 400mm |
| Material | Ultra-low Evaporation Rubber with Nylon Braided Sleeve |
FAN SPECS
| Property | Value |
|---|---|
| Model | F120 RGB Core Fans |
| Quantity | 2 |
| Dimension | 120 x 120 x 26mm |
| Speed | 500 - 1,800 ± 180 RPM |
| Airflow | 78.86 CFM |
| Air Pressure | 2.57 mm H2O |
| Noise | 33.88 dBA |
| Bearing | Fluid Dynamic Bearing |
| Power Consumption | 12 V DC, 0.2 A, 2.4 W |
| Fan Connector | 4-pin PWM |
| Life | 60,000 hours / 6 Years |
| Limited Warranty | 6 Years |
RGB CONTROLLER
| Property | Value |
|---|---|
| Dimensions | 63.2 x 53.2 x 12.8mm |
| Weight | 52.8g |
| Mounting | Magnet and 3M Dual Lock |
| Connection Cables | 1x USB 2.0 internal connector, 1x SATA power cable |
| Input Connector | 12V DC / 2.6A |
| RGB Lighting Channels | 3 |
| Output Channel Voltage | 5V DC |
| NZXT RGB Channel Output LED Qty. | Up to 40 LEDs per channel and up to 120 LEDs combined total for the total 3 channels |
COMPATIBLE SOCKET & CPU
| Property | Value |
|---|---|
| Intel | Intel Socket LGA 1700, 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron |
| AMD | AMD Socket AM5, AM4, sTRX4*, TR4* (*Threadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / ThreadripperC |
