| Specification | Details |
|---|---|
| Model | TUF Gaming GeForce RTX 3060 V2 OC Edition |
| Graphic Engine | NVIDIA® GeForce RTX™ 3060 |
| Bus Standard | PCI Express 4.0 |
| OpenGL | OpenGL® 4.6 |
| Video Memory | 12GB GDDR6 |
| Engine Clock | OC Mode: 1882 MHz (Boost Clock) |
| Gaming Mode: 1852 MHz (Boost Clock) | |
| CUDA Core | 3584 |
| Memory Speed | 15 Gbps |
| Memory Interface | 192-bit |
| Resolution | Digital Max Resolution: 7680 x 4320 |
| Interface | 2 x Native HDMI 2.1 |
| 3 x Native DisplayPort 1.4a | |
| HDCP Support | Yes (2.3) |
| Maximum Display Support | 4 |
| NVlink/ Crossfire Support | No |
| Accessories | 1 x TUF certificate of Reliability |
| 1 x Collection card | |
| 1 x Speedsetup Manual | |
| Software | ASUS GPU Tweak II & GeForce Game Ready Driver & Studio Driver |
| Dimensions | 11.81" x 5.63" x 2.13" Inch |
| 30.1 x 14.3 x 5.4 Centimeter | |
| Recommended PSU | 650W |
| Power Connectors | 1 x 8-pin |
| Slot | 2.7 Slot |
| AURA SYNC | ARGB |
- NVIDIA Ampere Streaming Multiprocessors: The building blocks for the world’s fastest, most efficient GPUs, the all-new Ampere SM brings 2X the FP32 throughput and improved power efficiency.
- 2nd Generation RT Cores: Experience 2X the throughput of 1st gen RT Cores, plus concurrent RT and shading for a whole new level of ray tracing performance.
- 3rd Generation Tensor Cores: Get up to 2X the throughput with structural sparsity and advanced AI algorithms such as DLSS. These cores deliver a massive boost in game performance and all-new AI capabilities.
- OC edition: Boost clock 1882 MHz (OC mode)/ 1852 MHz (Gaming mode)
- Axial-tech fan design has been newly tuned with a reversed central fan direction for less turbulence.
- Dual ball fan bearings can last up to twice as long as sleeve bearing designs.
- An all-aluminum shroud and metal backplate enhance durability.
- GPU Tweak II provides intuitive performance tweaking, thermal controls, and system monitoring.
