Features
Powered by GeForce® GTX 1660
NVIDIA Turing™ architecture and GeForce Experience™
Integrated with 6GB GDDR5 192-bit memory interface
WINDFORCE 2X Cooling System with alternate spinning fans
90 mm unique blade fans
Protection back plate
Core Clock
1830 MHz (Reference Card is 1785 MHz)
WINDFORCE 2X COOLING SYSTEM
WINDFORCE 2X cooling system features 2x 90mm unique blade fans, alternate spinning fan, a composite copper heat pipe direct touch GPU and 3D active fan functionality, together delivering an effective heat dissipation capacity for higher performance at lower temperatures.
| Feature | Specification |
|---|---|
| Graphics Processing | GeForce® GTX 1660 |
| Core Clock | 1830 MHz (Reference Card: 1785 MHz) |
| CUDA® Cores | 1408 |
| Memory Clock | 8002 MHz |
| Memory Size | 6 GB |
| Memory Type | GDDR5 |
| Memory Bus | 192 bit |
| Memory Bandwidth (GB/sec) | 192 GB/s |
| Card Bus | PCI-E 3.0 x 16 |
| Digital Max Resolution | 7680x4320@60Hz |
| Multi-view | 4 |
| Card Size | L=224mm W=121mm H=40mm |
| PCB Form | ATX |
| DirectX | 12 |
| OpenGL | 4.6 |
| Recommended PSU | 450W |
| Power Connectors | 8-Pin*1 |
| Output | DisplayPort 1.4 *3 |
| HDMI 2.0b *1 | |
| SLI Support | No |
| Accessories | 1. Quick guide |
| 2. Driver CD |
