WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 7 composite copper heat pipes, a large copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
RGB FUSION
With 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
ULTRA DURABLE
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
| Feature | Specification |
|---|---|
| Graphics Processing | Radeon™ RX 7700 XT |
| Core Clock | Boost Clock*: up to 2599 MHz |
| Game Clock*: up to 2276 MHz | |
| Stream Processors | 3456 |
| Memory Clock | 18 Gbps |
| Memory Size | 12 GB |
| Memory Type | GDDR6 |
| Memory Bus | 192 bit |
| Card Bus | PCI-E 4.0 |
| Digital Max Resolution | 7680x4320 |
| Multi-view | 4 |
| Card Size | L=302 W=130 H=56 mm |
| PCB Form | ATX |
| DirectX | 12 Ultimate |
| OpenGL | 4.6 |
| Recommended PSU | 700W |
| Power Connectors | 8 Pin*2 |
| Output | DisplayPort 2.1 *2 |
| HDMI 2.1 *2 | |
| Accessories | Quick guide |
