| Printing Technology |
|
| Print Method |
Impact dot matrix |
| Control Panel |
6 switches and 10 LEDs are located on the panel |
| Print Direction |
Bi-direction with logic seeking |
| Number of Pins in Head |
24 pins |
| Control Code |
ESC/P2 and IBM PPDS emulation |
| Print Speed |
|
| High Speed Draft |
10 cpi: 480 cps, 12 cpi: 576 cps |
| Draft |
10 cpi: 360 cps, 12 cpi: 432 cps, 15 cpi: 540 cps, 17 cpi: 308 cps, 20 cpi: 360 cps |
| Letter Quality |
10 cpi: 120 cps, 12 cpi: 144 cps, 15 cpi: 180 cps, 17 cpi: 205 cps, 20 cpi: 240 cps |
| Reliability |
|
| MVBF |
40 million lines (except print head) |
| MTBF |
20,000 Power On Hours (POH) (25% Duty) |
| Printhead Life |
400 million strokes/wire |
| Print Characteristics |
|
| Character Sets |
14 international character sets and one legal character sets |
| Bitmap Fonts |
Epson Draft / Epson Courier / Epson Roman / Epson Sans Serif / Epson Prestige / Epson Script / OCR-B / Orator / Orator-S / Epson Script C |
| Scalable Fonts |
Epson Roman / Sans Serif / Roman T / Sans Serif H: 10.5pt., 8pt. - 32pt. (every 2pt.) |
| Barcode |
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, POSTNET |
| Paper Path |
|
| Manual Insertion |
Front or Rear In, Top out |
| Push Tractor |
Front of Rear In, Top out |
| Pull Tractor |
Front or Rear or Bottom in, Top out |
| Paper Media |
|
| Cut Sheet (Single Sheet) |
Front Entry, Rear Entry, Copies: 1 Original + 5 Copies |
| Cut Sheet (Multi-part Forms) |
Front Entry, Rear Entry, Copies: 1 Original + 5 Copies |
| Envelopes |
Thickness: 0.16 - 0.52mm (Total) |
| Continuous Paper (Single Sheet) |
Front, Rear, Bottom Entry, Copies: 1 Original + 5 Copies |
| Continuous Paper (Multi-part Forms) |
Front, Rear, Bottom Entry, Copies: 1 Original + 5 Copies |
| Label (Base Sheet) |
Bottom Entry, Thickness: 0.16 - 0.19mm (Total) |
| Card |
Front, Rear Entry, Thickness: 0.22mm |
| Roll Paper |
Rear Entry, Diameter: 127mm, Thickness: 0.07 - 0.09mm |
| Line Spacing |
4.23mm (1/6”) or programmable in increments of 0.0706mm (1/360”) |
| General |
|
| Memory Buffer |
128 KB |
| Supported OS and Applications |
|
| Supported OS |
Microsoft® Windows® 2000 / XP / Vista / 7 / 8 / 8.1 / 10 |
| Utility |
Epson Status Monitor 3, Epson Printer Setting |
| Dimensions and Weight |
|
| Dimensions (W x D x H) |
639 x 402 x 256 mm |
| Weight |
13kg |
| Consumables |
|
| Ribbon Cartridge Black |
Approx. 15 million characters |
| Options |
|
| Options |
Epsonnet 10/100 Base TX Int.Printer Server, Pull Tractor Unit, Serial I/F Card No Buffer Type-B |
| Environmental Conditions (Operating) |
|
| Temperature |
5 - 35°C (Operating), 15 - 25°C (Operating) |
| Humidity |
10 - 80% RH (Operating), 30 - 60% RH (Operating) |
