| Printing | |
|---|---|
| Printing Technology | Printhead: PrecisionCore TFP" Printhead 1.3" |
| Nozzle Configuration | 3200 nozzles (800 nozzles x 4 channels x 1 head) |
| Maximum Print Resolution | 2400 X 1200 dpi |
| Minimum Ink Droplet Size | 4.0pl |
| Print Speed (CAD A1) | 34 sec |
| Ink | |
|---|---|
| Ink Type | Epson UltraChrome XD2 Pigment Ink |
| Colors | 4 Colors - Cyan, Magenta, Yellow, Black |
| Ink Capacity | Black: 50ml, 80ml |
| Cyan, Magenta, Yellow: 26ml, 50ml |
| Roll Media Handling | |
|---|---|
| Maximum Roll Diameter | 2" core |
| Maximum Roll Weight | Max. 110 mm/3kg |
| General | |
|---|---|
| Dimensions | 970 x 696 x 913 (WxDxH) |
| Warranty | 3-years warranty |
| Weight | 38kg (without ink cartridges) |
| Memory | 1GB |
| Power | |
|---|---|
| Power Consumption | Operating: Approx. 28W |
| Ready: Approx. 8W; Sleep: Approx. 1.6 W | |
| Power Off: Approx 0.2W | |
| Requirement | AC 100-240V |
| Frequency | 50/60Hz |
| Recommended Operating Temp & Humidity | Operating: 20 to 80% (no condensation) |
| Storage: 5 to 85% (no condensation) |
| Paper Handling | |
|---|---|
| Maximum Paper Width | Roll: 329 mm to 610 mm |
| Cutsheet (ASF): A4 to A3 | |
| Cutsheet (1 sheet): 210 mm to 610 mm | |
| Media Thickness | Roll: 0.05 mm to 0.21 mm |
| ASF/Cutsheet: 0.12 mm to 0.27 mm | |
| Media Type | Inkjet Coated Paper, Tracing Paper, Plain Paper |
| Side Margin | 3mm |
| Auto-Sheet Feeder | Yes (Up to A3) |
