| Model name |
24B1XHS |
| Panel |
23.8" (IPS) |
| Pixel Pitch (mm) |
0.2745 (H) × 0.2745 (V) |
| Effective Viewing Area (mm) |
527.04 (H) × 296.46 (V) |
| Brightness (typical) |
250 cd/m² |
| Contrast Ratio |
1000:1 (Typical) 20 Million : 1(DCR) |
| Response Time |
7ms (GtG) |
| Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
| Color Gamut |
NTSC 80.2% (CIE1976) / sRGB 97.6% (CIE1931) |
| Color Accuracy |
- |
| Optimum Resolution |
1920 x 1080 @ 60Hz |
| Display Colors |
16.7 Million |
| Signal Input |
VGA, HDMI 1.4 |
| HDCP Version |
- |
| USB Hub |
- |
| Power Supply |
19VDC, 1.31A |
| Power Consumption (typical) |
25W |
| Speakers |
no |
| Line in & Earphone |
Earphone |
| Wall-Mount |
75mm × 75mm |
| Adjustable Stand |
Tilt: -4° ~ 21.5° |
| Product without Stand (mm) |
- |
| Product with Stand (mm) |
419.9 (H) × 540.8 (W) × 186.8 (D) |
| Product without Stand (kg) |
- |
| Product with Stand (kg) |
3.05 |
| Cabinet Color |
Black |
| Regulatory Approvals |
BSMI / KC / KCC / e-Standby / RCM / MEPS / CE / CB / FCC |
