The Eaton 5A UPS is a single-phaseline-interactive UPS, with power ratings from 700 - 2200 VA. The UPS is available in a tower form factor. 5A UPS includes surge protection for outlets and circuit breaker protection, providing additional protection measures for peace of mind. Eaton 5A UPS also comes with multiple outlet formats – Schuko, NEMA universal, Universal, for ease of connection.
| Specifications | Details |
|---|---|
| Rating (VA/W) | 1200VA/650W |
| Format | Tower |
| Electrical Characteristics | |
| Input Voltage Range | 140–300 VAC |
| Frequency Range | 60/50 Hz (Auto sensing) |
| Surge Protection | Yes |
| Generator Compatible | Yes |
| Mute by Power Key | Yes |
| Circuit Breaker | Yes |
| Output | |
| Output Voltage | 230 VAC |
| Output Voltage Reg. (Battery Mode) | ±10% |
| Battery Wave Form | Stepped Sine Wave |
| Protection | PCBA Current Sensor (F/W Protection) |
| Output Backup Socket | DIN Model: (4) Schuko Outlets |
| NEMA Model: (6) NEMA Universal Outlets | |
| UNI Model: (4) Universal Outlets | |
| Transfer Time | 2–6ms typical, 10ms max |
| Battery | |
| Type | 12V/9Ah x1 |
| Floating Charging Voltage | 13.5–13.8V |
| Recharge Time | 4–6 hours recover to 90% capacity |
| Typical Battery Runtime | |
| IT Load (100W) | 25 min |
| 50% Load | 4.8 min |
| 75% Load | 25 s |
| Interface | |
| On / Off Switch | Yes |
| Indicator | LED |
| Communication–USB | No |
| Communication–RS232 | No |
| RJ11 Protection | No |
| Physical | |
| Dimension D x W x H (mm) | 370 x 138 x 165 |
| Weight (kg) | 6.25 |
| Package | Color Box |
| Part Numbers | |
| Schuko Outlets | 5A1200I-DIN |
| NEMA Outlets | 5A1200I-NEMA |
| Universal Outlets |
5A1200I-UNI
|
