| Projection Technology |
RGB liquid crystal shutter projection system (3LCD) |
| Brightness |
|
| White Light Output (Normal/Eco) |
3,300 lm |
| Colour Light Output |
3,300 lm |
| Connectivity |
|
| USB Interface |
USB Type B: 1 (For Firmware Update, Copy OSD Settings) |
| Analog Input |
D-Sub 15pin: 1 |
| Digital Input |
HDMI: 1 |
| Screen Size (Projected Distance) |
Standard Size: Tele: 22” to 259” [0.87 to 10.34 m], Wide: 30” to 350” [0.87 to 10.34 m] |
| Operating Temperature |
Low Altitude: 5 – 40 °C <41 – 104 °F>, High Altitude: 5 – 35 °C <41 – 95 °F> (20% – 80% Humidity, No Condensation) |
| Operating Altitude |
0 – 3,048 m <0 – 10,000 ft> |
| Start-Up Period |
Up to 6 seconds, Warm-up Period: 30 seconds |
| Cool Down Period |
Instant Off |
| Direct Power On/Off |
Direct Power On/Off: Yes |
| Dimension Excluding Feet (W x H x D) |
302 x 77 x 234 mm |
| Weight |
Approx. 2.4 kg |
| Air Filter |
Type: High Efficiency Filter |
| Maintenance Cycle |
6,000 / 12,000 hours*3 |
| Fan Noise |
Fan Noise (Normal / Eco): 37dB / 28dB |
| Power |
Power Supply Voltage: 100 - 240 V AC ±10%, 50/60 Hz |
| Projectors Facets |
Resolution: XGA, Contrast Ratio: 15,000:1, Brightness Range Lumens: 2000, Features: Quick Corner, Laser / Lamp: Lamp |
| Specifications of Main Parts: |
|
| LCD |
Native Resolution: XGA (1024 x 768), Size: 0.55” (C2fine) |
| Lightsource |
Type: 210W UHE, Life (Normal / Eco): 6,000 / 12,000 hours |
| Aspect Ratio |
4:3 |
| Projection Lens |
Type: No Optical Zoom / Focus (Manual), F-Number: 1.44, Focal Length: 16.70 mm, Throw Ratio: 1.00 – 1.35 (Digital Zoom), Zoom Ratio: 1.44 - 1.95 (Wide to Tele) |
