| Projection Technology |
RGB liquid crystal shutter projection system (3LCD) |
| Brightness |
|
| White Light Output (Normal/Eco) |
4,000 lm |
| Colour Light Output |
4,000 lm |
| Connectivity |
|
| USB Interface |
USB Type A: 1 (For Wireless LAN, Firmware Update, Copy OSD Settings), USB Type B: 1 (For Firmware Update, Copy OSD Settings) |
| Network |
Wireless: Optional (ELPAP11) |
| Analog Input |
Composite: 1 RCA, D-Sub 15pin: 1 |
| Digital Input |
HDMI: 1 |
| Audio Input |
2RCA (White & Red): 1 |
| Contrast Ratio |
16,000:1 |
| Screen Size (Projected Distance) |
Standard Size: Tele: 33” to 320” [1.10 to 10.89 m], Wide: 33” to 320” [0.91 to 9.07 m] |
| Geometric Correction |
Vertical/Horizontal Keystone: ±30° / ±30° (Auto Vertical Keystone only) |
| Quick Corner |
Yes |
| Operating Temperature |
Low Altitude: 5 – 40 °C <41 – 104 °F>, High Altitude: 5 – 35 °C <41 – 95 °F> (20% – 80% Humidity, No Condensation) |
| Operating Altitude |
0 – 3,048 m <0 – 10,000 ft> |
| Start-Up Period |
Up to 6 seconds, Warm-up Period: 30 seconds |
| Cool Down Period |
Instant Off |
| Direct Power On/Off |
Yes |
| Dimension Excluding Feet (W x H x D) |
302 x 77 x 234 mm |
| Weight |
Approx. 2.5 kg |
| Air Filter |
Type: High Efficiency Filter |
| Maintenance Cycle |
6,000 / 12,000 hours*3 |
| Fan Noise |
Fan Noise (Normal / Eco): 37dB / 28dB |
| Power |
Power Supply Voltage: 100 – 240 V AC ±10%, 50/60 Hz |
| Projectors Facets |
Resolution: WXGA, Contrast Ratio: 16,000:1, Brightness Range Lumens: 2000, Features: Wifi, Quick Corner, Laser / Lamp: Lamp |
| Optional Wireless Specifications: |
Supported Speed for Each Mode: IEEE 802.11b (2.4GHz): 11 Mbps2, IEEE 802.11n (2.4GHz): 72.2 Mbps2, IEEE 802.11a (5GHz): 54Mbps2, IEEE 802.11n (5GHz): 150 Mbps2, IEEE 802.11g (2.4GHz): 54 Mbps*2 |
| Wireless LAN Security |
Infrastructure: OPEN, WPA2/WPA3-PSK, Access Point: OPEN, WPA2-PSK (AES) |
| Specifications of Main Parts: |
|
| LCD |
Size: 0.59” (C2fine), Native Resolution: WXGA (1280 x 800) |
| Lightsource |
Type: 210W UHE, Life (Normal / Eco): 6,000 / 12,000 hours |
| Aspect Ratio |
16:10 |
| Projection Lens |
Type: Optical Zoom (Manual) / Focus (Manual), Zoom Ratio: 1 – 1.2, Focal Length: 16.90 – 20.28 mm, Throw Ratio: 1.30 – 1.56 (Wide to Tele), F-Number: 1.49 – 1.72 |
