LENOVO IDEAPAD 5-14ALC05-82LM00ATPH R5-5500U/8GB/512GB NVME/14/W10H/OFC19HS (GRY)

Technical Specification

Lenovo Slim 5 14ALC05

Part Number 82LM00ATPH

PERFORMANCE

Processor AMD Ryzen 5 5500U (6C / 12T, 2.1 / 4.0GHz, 3MB L2 / 8MB L3)

Graphics Integrated AMD Radeon Graphics

Chipset: AMD SoC Platform

Memory 8GB Soldered DDR4-3200
Memory Slots Memory soldered to systemboard, no slots, dual-channel (8GB or 16GB model)
Max Memory 8GB soldered memory, not upgradable

Storage 512GB SSD M.2 2242 PCIe 3.0x4 NVMe
Storage Support One drive, up to 512GB M.2 2242 SSD or 512GB M.2 2280 SSD
Card Reader: 4-in-1 Card Reader
Optical: None

Audio Chip: High Definition (HD) Audio, Realtek ALC3287 codec
Speakers Stereo speakers, 2W x2, Dolby Audio

Camera: 720p with Privacy Shutter

Microphone: 2x, Array

Battery: Integrated 56.5Wh

Max Battery Life: MobileMark 2018: 8.3 hr (56.5Wh)

Power Adapter: 65W Round Tip Wall-mount

DESIGN
Display: 14" FHD (1920x1080) IPS 300nits Anti-glare, 45% NTSC
Touchscreen: None
Keyboard Backlit, English
Case Color: Platinum Grey
Surface Treatment Anodizing
Case Material Aluminium (Top), PC + ABS (Bottom)

Dimensions (WxDxH)
321.57 x 211.59 x 17.9-19.9 mm (12.66 x 8.33 x 0.7-0.78 inches)

Weight: 1.39 kg (3.06 lbs)

CONNECTIVITY
Ethernet None
WLAN + Bluetooth 11ac, 2x2 + BT5.0
Standard Ports
1x HDMI 1.4b
1x headphone / microphone combo jack (3.5mm)
1x card reader
1x USB 3.2 Gen 1
1x USB-C 3.2 Gen 1 (support data transfer, Power Delivery 3.0 and DisplayPort 1.2)
1x USB 3.2 Gen 1 (Always On)
Optional Ports 1x power connector (plastic bottom models only)

SECURITY & PRIVACY
Security Chip Firmware TPM 2.0
Fingerprint Reader Touch Style
Other Security Camera privacy shutter
