Technical Specifications

PERFORMANCE

Processor Intel Celeron N4020 (2C / 2T, 1.1 / 2.8GHz, 4MB)

Graphics Integrated Intel UHD Graphics 600

Chipset Intel SoC Platform

Memory 8GB Soldered LPDDR4-2133

Memory Slots Memory soldered to systemboard, no slots

Max Memory 8GB soldered memory, not upgradable

Storage 128GB eMMC 5.1

Storage Support 128GB eMMC 5.1 on systemboard MicroSD card, supports FAT32 file up to 128GB

Card Reader MicroSD Card Slot

Optical None

Audio Chip High Definition (HD) Audio

Speakers Stereo speakers, 1W x2, Dolby Audio Premium

Camera Front 2.0MP / Rear 5.0MP

Microphone Mono

Battery Integrated 39Wh

Max Battery Life Local Video (1080p) Playback: 8 hr

Power Adapter 45W Round Tip Wall-mount

DESIGN

Display 10.1" HD (1280x800) IPS 300nits Glossy

Touchscreen 10-point Multi-touch

Keyboard (Docking) :Keyboard Dock (Pogo Pin, Detachable)

Case Color Mineral Grey

Surface Treatment Metallic painting

Case Material PC + GF (25%~40%)

Dimensions (WxDxH) Pad: 249 x 178 x 9.5 mm (9.8 x 7.01 x 0.37 inches) Keyboard dock: 249 x 186 x 8.5 mm (9.8 x 7.32 x 0.33 inches)

Weight WiFi Pad: 600 g (1.32 lbs) Keyboard dock: 535 g (1.18 lbs)

SOFTWARE

Others: Miracast

Operating System Windows 10 Pro 64

Bundled Software None

CONNECTIVITY

Ethernet None

WLAN + Bluetooth 11ac, 1x1 + BT4.2

Standard Ports

        1x power connector

1x USB-C 3.2 Gen 1 (support data transfer only)

1x headphone / microphone combo jack (3.5mm)

1x Pogo pin dock connector

2x USB 2.0 (on keyboard dock)

1x microSD card slot (WLAN model)

Optional Ports Keyboard Dock (Pogo Pin, Detachable)

SECURITY & PRIVACY

Security Chip Firmware TPM 2.0 integrated in chipset

Fingerprint Reader None
