Technical Specifications

Model:  Lenovo Legion 5 15ACH6H 82JU00YMPH

Processor:  AMD Ryzen 7 5800H (8C / 16T, 3.2 / 4.4GHz, 4MB L2 / 16MB L3)
Graphics:  NVIDIA GeForce RTX 3060 6GB GDDR6, Boost Clock 1425 / 1702MHz, TGP 130W
Chipset:  AMD SoC Platform

Memory:  2x 8GB SO-DIMM DDR4-3200
Memory Slots:  Two DDR4 SO-DIMM slots, dual-channel capable
Max Memory:  Up to 32GB DDR4-3200 offering

Storage:  512GB SSD M.2 2280 PCIe 3.0x4 NVMe
Storage Support:  Up to two drives, 2x M.2 SSD ? M.2 2242 SSD up to 512GB ? M.2 2280
Card Reader:  None

Optical:  None

Audio Chip:  High Definition (HD) Audio, Realtek ALC3306 codec

Speakers:  Stereo speakers, 2W x2, Nahimic Audio

Camera:  720p with E-camera Shutter

Microphone:  2x, Array

Battery:  Integrated 80Wh

Max Battery Life:  MobileMark 2018: 9.2 hr (80Wh)

Power Adapter:  300W Slim Tip (3-pin)

DESIGN
Display:  15.6" WQHD (2560x1440) IPS 300nits Anti-glare, 165Hz, 100% sRGB, Dolby Vision, Free-Sync, G-Sync, DC dimmer

Touchscreen:  None

Keyboard:  Blue Backlit, English

Case Color:  Stingray (Top), Dove Grey (Bottom)

Surface Treatment:  Painting

Case Material:  PC + ABS (Top), PC + ABS (Bottom)

Dimensions (WxDxH):  362.56 x 260.61 x 22.5-25.75 mm (14.27 x 10.26 x 0.89-1.01 inches)

Weight:  2.4 kg (5.3 lbs)

CONNECTIVITY
Ethernet:  100/1000M
WLAN + Bluetooth Wi-Fi 6 11ax, 2x2 + BT5.1

Standard Ports
3x USB 3.2 Gen 1
1x USB 3.2 Gen 1 (Always On)
1x USB-C 3.2 Gen 2 (support data transfer and DisplayPort 1.4)
1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery and DisplayPort 1.4)
1x HDMI 2.1
1x Ethernet (RJ-45)
1x Headphone / microphone combo jack (3.5mm)
1x Power connector
