LENOVO LEGION 5-15ARH7H 82RD001APH R7-6800H | Gaming Laptop And AutoCAD Users

SPECIFICATION

• PROCESSOR: AMD Ryzen 7 6800H
• DISPLAY: 15.6" WQHD (2560x1440) IPS 300nits Anti-glare
• MEMORY: 2x 8GB SO-DIMM DDR5-4800
• STORAGE: 512GB SSD M.2 2280 PCIe 4.0x4 NVMe
• GPU: NVIDIA GeForce RTX 3060 6GB GDDR6
• OS: Windows 11 Home
• COLOR:Grey

Technical Specification

Part Number:  82RD001APH

PERFORMANCE
Processor:  AMD Ryzen 7 6800H (8C / 16T, 3.2 / 4.7GHz, 4MB L2 / 16MB L3)
Graphics:  NVIDIA GeForce RTX 3060 6GB GDDR6, Boost Clock 1702MHz, TGP 140W
Chipset:  AMD SoC Platform

Memory:  2x 8GB SO-DIMM DDR5-4800
Memory Slots:  Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory:  Up to 32GB DDR5-4800 offering

Storage:  512GB SSD M.2 2280 PCIe 4.0x4 NVMe
Storage Support:  Up to two drives, 2x M.2 SSD ? M.2 2280 SSD up to 1TB ? M.2 2242 SSD up to 512GB

Card Reader:  None
Optical:  None

Audio Chip:  High Definition (HD) Audio, Realtek ALC3287 codec
Speakers:  Stereo speakers, 2W x2, Nahimic Audio

Camera:  FHD 1080p with E-camera Shutter

Microphone:  2x, Array

Battery:  Integrated 80Wh
Max Battery Life:  Model with 80Wh battery: MobileMark 2018: 10.8 hr Local video (1080p)
playback@150nits: 17.8 hr

Power Adapter: 230W Slim Tip (3-pin)

DESIGN
Display:  15.6" WQHD (2560x1440) IPS 300nits Anti-glare, 165Hz, 100% sRGB, Dolby Vision, Free-Sync, G-Sync, DC dimmer

Touchscreen:  None

Keyboard:  4-Zone RGB Backlit, English

Case Color:  Storm Grey

Surface Treatment:  Anodizing

Case Material:  Aluminium (Top), PC + ABS (Bottom)

Dimensions (WxDxH):  358.8 x 262.35 x 19.99 mm (14.13 x 10.33 x 0.79 inches)
Weight:  Around 2.4 kg (5.3 lbs)

SOFTWARE
Operating System Windows 11 Home 64, English
Bundled Software Office Home and Student 2021

CONNECTIVITY
Ethernet 100/1000M
WLAN + Bluetooth Wi-Fi 6 11ax, 2x2 + BT5.2

Standard Ports
2x USB 3.2 Gen 1
1x USB 3.2 Gen 1 (Always On)
2x USB-C 3.2 Gen 2 (support data transfer and DisplayPort 1.4)
1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 135W and DisplayPort 1.4)
1x HDMI, up to 8K/60Hz
1x Ethernet (RJ-45)
1x Headphone / microphone combo jack (3.5mm)
1x Power connector

SECURITY & PRIVACY
Security Chip Firmware TPM 2.0

Fingerprint Reader None

Other Security E-Camera shutter
