Technical Specifications
Model: Lenovo Legion 5 Pro 16ACH6H 82JQ00R7PH
PERFORMANCE
Processor: AMD Ryzen 7 5800H (8C / 16T, 3.2 / 4.4GHz, 4MB L2 / 16MB L3)
Graphics: NVIDIA GeForce RTX 3070 8GB GDDR6, Boost Clock 1560 / 1620MHz, TGP 140W
Chipset: AMD SoC Platform
Memory: 2x 8GB SO-DIMM DDR4-3200
Memory Slots: Two DDR4 SO-DIMM slots, dual-channel capable
Max Memory: Up to 32GB DDR4-3200 offering
Storage: 1TB SSD M.2 2280 PCIe 3.0x4 NVMe
Storage Support: Up to two drives, 2x M.2 SSD ? M.2 2242 SSD up to 512GB ? M.2 2280 SSD up to 1TB
Card Reader: None
Optical: None
Audio Chip: High Definition (HD) Audio, Realtek ALC3306 codec
Speakers: Stereo speakers, 2W x2, Nahimic Audio
Camera: 720p with E-camera Shutter
Microphone: 2x, Array
Battery: Integrated 80Wh
Max Battery Life: MobileMark 2018: 4.2 hr (discrete mode) or 8.1 hr (hybrid mode)
Power Adapter: 300W Slim Tip (3-pin)
DESIGN
Display: 16" WQXGA (2560x1600) IPS 500nits Anti-glare, 165Hz, 100% sRGB, Dolby Vision, HDR 400, Free-Sync, G-Sync, DC dimmer
Touchscreen: None
Color Calibrator: Factory Color Calibration
Keyboard: 4-Zone RGB Backlit, English
Case Color: Storm Grey (Top), Black (Bottom)
Surface Treatment: Anodizing
Case Material: Aluminium (Top), Aluminium (Bottom)
Dimensions (WxDxH): 356 x 260.4-264.4 x 21.7-26.85 mm (14.02 x 10.25-10.41 x 0.85-1.07 inches)
Weight: 2.45 kg (5.4 lbs)
CONNECTIVITY
Ethernet 100/1000M
WLAN + Bluetooth Wi-Fi 6 11ax, 2x2 + BT5.1
Standard Ports
3x USB 3.2 Gen 1
1x USB 3.2 Gen 1 (Always On)
1x USB-C 3.2 Gen 2 (support data transfer and DisplayPort 1.4)
1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery and DisplayPort 1.4)
1x HDMI 2.1
1x Ethernet (RJ-45)
1x Headphone / microphone combo jack (3.5mm)
1x Power connector
