Technical Specification

Part Number :  82RF004MPH

PERFORMANCE
Processor:  Intel Core i7-12700H, 14C (6P + 8E) / 20T, P-core 2.3 / 4.7GHz, E-core 1.7 / 3.5GHz, 24MB
Graphics:  NVIDIA GeForce RTX 3060 6GB GDDR6, Boost Clock 1702MHz, TGP 140W
Chipset:  Intel SoC Platform

Memory:  2x 8GB SO-DIMM DDR5-4800
Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory Up to 32GB DDR5-4800 offering

Storage:  1TB SSD M.2 2280 PCIe 4.0x4 NVMe
Storage Support Up to two drives, 2x M.2 SSD ? M.2 2242 SSD up to 512GB ? M.2 2280
SSD up to 1TB

RAID Preset:  None

Card Reader:  None

Optical:  None

Audio Chip:  High Definition (HD) Audio, Realtek ALC3287 codec

Speakers:  Stereo speakers, 2W x2, Nahimic Audio

Camera:  720p with E-camera Shutter

Microphone:  2x, Array

Battery:  Integrated 80Wh

Max Battery Life:  MobileMark 2018: 4.01 hr (discrete mode) or 6.55 hr (hybrid mode)

Power Adapter:  300W Slim Tip (3-pin)

DESIGN
Display:  16" WQXGA (2560x1600) IPS 500nits Anti-glare, 165Hz, 100% sRGB, Dolby Vision, HDR 400, G-Sync, DC dimmer

Touchscreen:  None

Color Calibrator:  Factory Color Calibration

Keyboard:  4-Zone RGB Backlit, English

Case Color:  Storm Grey

Surface Treatment:  Anodizing

Case Material:  Aluminium (Top), Aluminium (Bottom)

Dimensions (WxDxH):  359.9 x 264.4 x 19.9 mm (14.17 x 10.41 x 0.78 inches)=

Weight:  2.49 kg (5.49 lbs)

CONNECTIVITY
Ethernet 100/1000M
WLAN + Bluetooth Wi-Fi 6 11ax, 2x2 + BT5.1

Standard Ports
2x USB 3.2 Gen 1
1x USB 3.2 Gen 1 (Always On)
1x USB-C 3.2 Gen 2 (support data transfer and DisplayPort 1.4)
1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 135W and DisplayPort 1.4)
1x Thunderbolt 4 / USB4 40Gbps (support data transfer and DisplayPort 1.4)
1x HDMI, up to 8K/60Hz
1x Ethernet (RJ-45)
1x Headphone / microphone combo jack (3.5mm)
1x Power connector
