Lenovo ThinkPad L14 Gen 4 Overview

Design and Build:

  • Color: Black
  • Finish: Durable, high-quality plastic with a matte finish.
  • Form Factor: Traditional clamshell laptop design with a sturdy build, designed for reliability in a business environment.

Display:

  • Size: 14 inches diagonal
  • Resolution: Full HD (1920 x 1080) for clear and sharp visuals.
  • Type: Anti-glare display to reduce reflections and eye strain.
  • Brightness: Standard brightness suitable for indoor use.

Performance:

  • Processor: Intel Core™ i7-1355U
    • Specifications: 10-core processor (2 performance cores and 8 efficiency cores), up to 5.0 GHz max turbo frequency.
  • Memory:
    • Total RAM: 16 GB
    • Configuration: 8 GB onboard + 8 GB removable SO-DIMM, providing ample memory for multitasking and demanding applications.
  • Storage:
    • Type: 512 GB PCIe® NVMe™ M.2 SSD
    • Details: Offers fast data access and enough storage for files and applications.

Graphics:

  • Integrated Graphics: Intel Iris® Xe Graphics, suitable for everyday tasks and light multimedia use.

Audio:

  • Speakers: Stereo speakers with Dolby Audio.
  • Microphone: Dual array microphones for clear voice input during calls.

Keyboard and Input:

  • Keyboard: Full-size, spill-resistant, backlit keyboard with TrackPoint and multi-touch touchpad for efficient typing and navigation.
  • Pointing Device:
    • Touchpad: Responsive touchpad for precise control.
    • TrackPoint: Red pointing stick in the center of the keyboard for an alternative input method.

Camera:

  • Front Camera: HD (720p) webcam for video conferencing.
  • Features: Integrated with a privacy shutter for enhanced security.

Ports and Connectivity:

  • USB Ports:
    • 2 USB 3.2 Gen 1 Type-A
    • 1 USB 3.2 Gen 2 Type-C (supports Power Delivery and DisplayPort™ 1.4)
    • 1 USB 3.2 Gen 2 Type-C (supports Power Delivery and DisplayPort™ 1.4)
    • 1 USB 3.2 Gen 1 Type-C (Power Delivery, data transfer, and optional PowerShare)
  • HDMI: 1 HDMI 2.0 for connecting to external monitors.
  • Ethernet: RJ-45 port for wired network connections.
  • Audio Jack: 1 headphone / microphone combo.
  • Card Reader: MicroSD card reader for additional storage options.
  • Wireless: Intel Wi-Fi 6E (2x2) and Bluetooth® 5.1 for fast and reliable wireless connectivity.

Power and Battery:

  • Power Supply: 65 W USB Type-C® power adapter.
  • Battery: 3-cell, 45 Wh Li-ion polymer battery.
  • Battery Life: Varies based on usage, typically up to 10 hours for standard tasks.

Security Features:

  • Fingerprint Reader: Integrated for secure and convenient login.
  • TPM: Trusted Platform Module 2.0 for enhanced security and data protection.
  • Smart Card Reader: Optional for secure authentication and access.

Operating System:

  • Pre-installed: Windows 10 Pro (Upgradeable to Windows 11 Pro)

Certifications:

  • Energy Star Certified: Meets energy efficiency standards.
  • MIL-STD 810H: Passed various military-grade durability tests to ensure reliability in harsh conditions.


    Category Specification
    Processor Intel Core i7-1355U, 10C (2P + 8E) / 12T, P-core 1.7 / 5.0GHz, E-core 1.2 / 3.7GHz, 12MB
    Graphics Integrated Intel Iris Xe Graphics
    Chipset Intel SoC Platform
    Memory 16GB SO-DIMM DDR4-3200 (2x 8GB)
    Memory Slots Two DDR4 SO-DIMM slots, dual-channel capable
    Max Memory Up to 64GB DDR4-3200
    Storage 512GB SSD M.2 2242 PCIe 4.0x4 NVMe Opal 2.0
    Storage Support One drive, up to 2TB M.2 2242 SSD
    Storage Slot One M.2 2242 PCIe 4.0 x4 slot
    Card Reader microSD Card Reader
    Optical None
    Audio Chip Non-vPro models: High Definition (HD) Audio, Realtek ALC3287 codec
    Speakers Stereo speakers, 2W x2, Dolby Audio
    Camera HD 720p with Privacy Shutter
    Microphone 2x Array
    Battery Integrated 46.5Wh
    Power Adapter 65W USB-C (3-pin)
    DESIGN
    Display 14" FHD (1920x1080) IPS 250nits Anti-glare, 45% NTSC
    Touchscreen None
    Keyboard Backlit, English
    Case Color Thunder Black
    Case Material PC-ABS (Top), PC-ABS (Bottom)
    Dimensions (WxDxH) 325.4 x 217 x 19.83 mm (12.81 x 8.54 x 0.78 inches)
    Weight Starting at 1.4 kg (3.09 lbs)
    SOFTWARE
    Operating System Windows 11 DG Windows 10 Pro 64, English
    Bundled Software None
    CONNECTIVITY
    Ethernet 100/1000M (RJ-45)
    WLAN + Bluetooth Intel Wi-Fi 6E AX211, 11ax 2x2 + BT5.3
    WWAN Fibocom L860-GL-16, 4G LTE CAT16, with Embedded eSIM
    SIM Card None
    NFC None
    Standard Ports 1x USB 3.2 Gen 1
    1x USB 3.2 Gen 1 (Always On)
    1x USB-C 3.2 Gen 2 (data transfer, Power Delivery 3.0, DisplayPort 1.4)
    1x Thunderbolt 4 / USB4 40Gbps (data transfer, Power Delivery 3.0, DisplayPort 1.4)
    1x HDMI 2.1, up to 4K/60Hz
    1x Headphone / microphone combo jack (3.5mm)
    1x Ethernet (RJ-45)
    1x microSD card reader
    Optional Ports 1x Nano-SIM Card Slot (configured)
    Docking Various docking solutions supported via Thunderbolt or USB-C
    Monitor Cable None
    SECURITY & PRIVACY
    Smart Card Reader None
    Security Chip Discrete TPM 2.0 Enabled
    Fingerprint Reader Touch Style, Match-on-Chip, Integrated in Power Button
    Physical Locks Kensington Nano Security Slot, 2.5 x 6 mm
    Other Security Camera privacy shutter
    MANAGEABILITY
    System Management Non-vPro
    SERVICE
    Base Warranty 1-year, Courier or Carry-in
    Included Upgrade 3Y Premier Support Upgrade from 1Y Courier/Carry-in
    ACCESSORIES
    Bundled Accessories None
    CERTIFICATIONS
    Green Certifications ENERGY STAR 8.0
    EPEAT Gold Registered
    ErP Lot 6
    ErP Lot 26
    RoHS compliant
    TCO Certified 9.0
    Mil-Spec Test MIL-STD-810H military test passed
