SILVERSTONE POWERSUPPLY STF60F-ES230 80PLUS 230V 600W

SILVERSTONE POWERSUPPLY STF60F-ES230 80PLUS 230V 600W

Name: SILVERSTONE POWERSUPPLY STF60F-ES230 80PLUS 230V 600W
Brand: BlueArm Computer Store
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Product SKU: N/A

Available:

Only 0 item in stock

0 item in stock

In stock

Out of stock

Back in stock

₱0.00

Description
Reviews

Product Specifications

Product No.

SST-ST60F-ES230

Color

Black（Lead-Free Paint）

Max. DC Output

600W

Power density

332W per liter

Load Range

Output	+3.3V	+5V	+12V	+5VSB	-12V
Max.(Amps)	20A	20A	46A	2.5A	0.3A
Peak (Amps)	/	/	/	/	/
Min.(Amps)	0A	0A	0A	0A	0A
Range (%)	±5%	±5%	±5%	±5%	±10%
Line Reg.(%)	±1%	±1%	±1%	±1%	±1%
Ripple(mVp-p)	50mV	50mV	120mV	50mV	120mV

Combined +3.3V & +5V

120W

Combined +12V

552W

Input Voltage

180V~264V

Input Frequency Range

47Hz~63Hz

PFC

Active PFC（PF>0.9 at full load）

Efficiency

82% ~ 85% at 20% ~ 100% loading

MTBF

100,000 hours

Operating temperature

0°C ~ 40°C

Protection

Over power protection

Over voltage protection

Short circuit protection

Connectors

1 x 24 / 20-Pin motherboard connector（500mm）

1 x 8 / 4-Pin EPS / ATX 12V connector（750mm）

2 x 8 / 6-Pin PCIE connector（"500mm / 150mm"）

4 x SATA connector（"500mm / 150mm" x 2）

3 x 4-Pin Peripheral connector（500mm / 150mm / 150mm）

1 x 4-Pin Floppy connector（500mm / 150mm / 150mm / 150mm）

Cooling System

Single 120mm silent fan

Noise Level

18 dBA minimum

Certification

80 PLUS

Form factor

ATX

Dimension

150 mm (W) x 86 mm (H) x 140 mm (D)

Weight

1.41 kg

Other

GPU Support list
