Specifications
| Model number1 | WD10EZEX |
| Interface | SATA 6 Gb/s |
| Formatted capacity2 | 1,000,204 MB |
| Advanced Format (AF) | Yes |
| Form factor | 3.5-inch |
| RoHS compliant3 | Yes |
Performance
| Data transfer rate (max) Buffer to host Host to/from drive (sustained) |
6 Gb/s 150 MB/s |
| Cache (MB) | 64 |
| Rotational speed (RPM) | 7200 RPM Class |
Reliability / Data Integrity
| Load/unload cycles4 | 300,000 |
| Non-recoverable read errors per bits read | <1 in 1014 |
Power Management
| 12VDC ±10% (A, peak) | 2.5 |
| Average power requirements (W) Read/Write Idle Standby/Sleep |
6.8 6.1 1.2 |
Environmental Specifications6
| Temperature (°C) Operating Non-operating |
0 to 60 -40 to 70 |
| Shock (Gs) Operating (2 ms, write) Operating (2 ms, read) Non-operating (2 ms) |
30 65 350 |
| Acoustics (dBA)7 Idle Seek (average) |
29 30 |
Physical Dimensions
| Height (in./mm, max) | 1.028/25.4 |
| Length (in./mm, max) | 5.787/147 |
| Width (in./mm, ± .01 in.) | 4/101.6 |
| Weight (lb./kg, ± 10%) | 0.99/0.45 |
